ZE3208MB@电动泵

ZE-系列@电动泵 Enerpac high 压Apumps features Z-Class high-efficiency pump design; higher oil 流量 and by-pass 压力, cooler running and requires 18% less current draw than comparable pumps 高效双级泵设计,流量更大,旁路压力高,散热性能好,工作电流较同类产品低18% 高强度模塑电控箱保护电路,电机及数显装置,使泵适应更苛刻的工作环

ZE-系列@电动泵
Enerpac high 压Apumps features Z-Class high-efficiency pump design; higher oil 流量 and by-pass 压力, cooler running and requires 18% less current draw than comparable pumps

高效双级泵设计,流量更大,旁路压力高,散热性能好,工作电流较同类产品低18%
高强度模塑电控箱保护电路,电机及数显装置,使泵适应更苛刻的工作环境
IP54级保护及绝缘
带背光照明的LCD可提供其他便携式泵不具有系统诊断和信息显示功能(电磁阀型号标配,其他型号选配)
全封闭式带风冷散热装置电动机,延长泵的使用寿命及适应苛刻的工作环境
手动阀和电磁阀内置用户可调溢流阀,阀上油口尺寸为3/8”NPT
电机上都配有钢制风扇保护罩
40um空气滤清器
钢制油箱经久耐用

Pump *
Configuration
For use
with
cylinder
Valve Function Valve
Model
Number



VM = manual
VE = electric
Useable
Oil
Capacity




gallon
Pump Series / Model Number * (two stage)
W = 400 volt / 3 phase / 50 Hz
ZE3-series
1 hp

Output Flow Rate
at 10,000 psi:
40 in3/min
ZE4-series
1.5 hp

Output Flow Rate
at 10,000 psi:
60 in3/min
ZE5-series
3.0 hp

Output Flow Rate
at 10,000 psi:
120 in3/min
ZE6-series
7.5 hp

Output Flow Rate
at 10,000 psi:
200 in3/min
S/A D/A Adv. Hold Retr.
VM32 2.0 ZE3208MB ZE4208MB - -
VM33 2.0 ZE3308MB ZE4308MB - -
VM33 5.0 ZE3320MB ZE4320MB ZE5320MG ZE6320MG
VM33 10.0 ZE3340MB ZE4340MB ZE5340MG ZE6340MG
VM43 2.0 ZE3408MB ZE4408MB
VM43 5.0 ZE3420MB ZE4420MB ZE5420MG ZE6420MG
VM43 10.0 ZE3440MB ZE4440MB ZE5440MG ZE6440MG
VM32 2.0 ZE3208LB ZE4208LB
VM32 2.5 ZE3210LB ZE4210LB ZE5210LG ZE6210LG
VM33 5.0 ZE3320LB ZE4320LB ZE5320LG ZE6320LG
VM33 10.0 ZE3340LB ZE4340LB ZE5340LG ZE6340LG
VM43 5.0 ZE3420LB ZE4420LB ZE5420LG ZE6420LG
VM43 10.0 ZE3440LB ZE4440LB ZE5440LG ZE6440LG
VE32D 1.0 ZE3104DB ZE4104DB - -
VE32D 2.0 ZE3108DB ZE4108DB - -
VE32D 2.5 ZE3110DB ZE4110DB ZE5110DG ZE6110DG
VE32D 5.0 ZE3120DB ZE4120DB ZE5120DG ZE6120DG
VE33 2.0 ZE3308SB ZE4308SB - -
VE33 2.5 ZE3310SB ZE4310SB ZE5310SG ZE6310SG
VE33 5.0 ZE3320SB ZE4320SB ZE5320SG ZE6320SG
VE43 2.0 ZE3408SB ZE4408SB - -
VE43 2.5 ZE3410SB ZE4410SB ZE5410SG ZE6410SG
VE43 5.0 ZE3420SB ZE4420SB ZE5420SG ZE6420SG
VE43 10.0 ZE3440SB ZE4440SB ZE5440SG ZE6440SG

* For options, other configurations, voltage, models and weights download catalog pages.
M = manual valve, no electric box or LCD;
L = manual valve, with electric box and LCD;
D = solenoid dump valve, with electric box and LCD;
S = solenoid 3-position valve, with electric box and LCD.
